Orange Color Refractory Pan Mixer Refractory Mixer Machine 500L Input Capacity

Orange Color Refractory Pan Mixer Refractory Mixer Machine 500L Input Capacity

    • Orange Color Refractory Pan Mixer Refractory Mixer Machine 500L Input Capacity
  • Orange Color Refractory Pan Mixer Refractory Mixer Machine 500L Input Capacity

    Product Details:

    Place of Origin: JIAOZHOU CHINA
    Brand Name: PERMIX
    Certification: CE
    Model Number: PMC330

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: Negotiation
    Packaging Details: Export Standard Package
    Delivery Time: 15-20 days
    Payment Terms: L/C, T/T
    Supply Ability: 5-10 units per month
    Contact Now
    Detailed Product Description
    Input Capacity: 500L Input Weight: 800kgs
    Output Capacity: 330L Mixing Power: 15kw
    Blade QTY: 1*2 Color: Orange
    High Light:

    refractory mixer machine

    ,

    refractory castable mixer machine

    PMC330 Refractory Planetary Mixer easy installation and maintenance



    Wear - Resistant Alloy Plates Planetary Concrete Mixer Stainless Steel Materials
    Transmission System


    The gearbox unit specially designed for a balanced distributor of power to the various mixing device and realize rotation and revolution, ensuring a high efficiency and low noise rotation. The structure is compact, and the deep mixing the internal part of the gearbox will not adhere to the material and increase the cleaning space of the blender.



    Maintaining Door



    The safety control device ensures that the mixer will not start during maintenance. Large size maintaining door for easy maintenance and cleaning. Orange Color Refractory Pan Mixer Refractory Mixer Machine 500L Input Capacity 0



    Technical Specification
    ITEM/(PMC) PMC
    50
    PMC
    100
    PMC
    150
    PMC
    250
    PMC
    330
    PMC
    500
    PMC
    750
    PMC
    1000
    PMC
    1250
    PMC
    1500
    PMC
    2000
    PMC
    2500
    PMC
    3000
    PMC 4000
    Feeding Capacity (L) 75 150 225 375 500 750 1125 1500 1875 2250 3000 3750 4500 6000
    Output Capacity (L) 50 100 150 250 330 500 750 1000 1250 1500 2000 2500 3000 4000
    Feeding Weight (kg) 120 240 360 600 800 1200 1800 2400 3000 3600 4800 6000 7200 9600
    Mixing Power (kw) 3 5.5 7.5 11 15 18.5 30 37 45 55 75 90 110 132
    Discharging Power (kw) Pneumatic Discharge(Hydraulic Discharge Optional) 3 3 3 4 4 4 4
    Mixing Star*Blade 1*2 1*2 1*2 1*2 1*2 1*2 1*3 2*2 2*2 2*2 3*2 3*3 3*3 3*3
    Side Scraper 1 1 1 1 1 1 1 1 1 1 1 1 1 1
    Discharge Scraper - - 1 1 1 1 1 1 1 1 2 2 2 2
    Weight (kg) 750 1000 1300 1500 2000 2400 3900 5500 6000 6500 9200 11000 12000 17500
    Lifting Power (kw) - - - 3 4 4 7.5 11 11 15 18.5 22 30 -
    Dimension (L*W*H) mm 950*
    790*
    1200
    1664*
    1453*
    1487
    1670*
    1460*
    1620
    1860*
    1650*
    1780
    1870*
    1870*
    1855
    2230*
    2080*
    1880
    2580*
    2340*
    2195
    2891*
    2602*
    2237
    3058*
    2756*
    2395
    3223*
    2902*
    2470
    3625*
    3230*
    2695
    3893*
    3550*
    2875
    3893*
    3550*
    3085

    4594*
    4150*
    3634
