Steel Stationary Block Making Planetary Mixer PMC3000 High Homogenization Mixing

Steel Stationary Block Making Planetary Mixer PMC3000 High Homogenization Mixing

    • Steel Stationary Block Making Planetary Mixer PMC3000 High Homogenization Mixing
  • Steel Stationary Block Making Planetary Mixer PMC3000 High Homogenization Mixing

    Product Details:

    Place of Origin: JIAOZHOU CHINA
    Brand Name: PERMIX
    Certification: CE
    Model Number: PMC3000

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: Negotiation
    Packaging Details: Export Standard Package
    Delivery Time: 15-20 days
    Payment Terms: L/C, T/T
    Supply Ability: 5-10 units per month
    Contact Now
    Detailed Product Description
    Material: Steel Input Capacity: 4500L
    Side Scraper QTY: 1 Color: Orange
    Weight: 12000kgs Bottom Scraper QTY: 1
    High Light:

    cement brick making machine

    ,

    commercial cement mixer

    High Homogenization Of Mixing Counter Current Mixer 1-3 Unloading Doors PMC3000




    Features of Planetary mixer

    Mixer has good deaeration effect, the cylinder body can be designed to be heated or cooled according to customers' needs. The cover is hydraulic lifting, convenient to operate and clean and the cylinder body can move freely.
    Planetary mixer is a new type of high efficiency, stirring without dead corner equipment; it has a unique form of stirring. Cylinder with special seal structure and have the pressure or vacuum stirring. Planet drive the two stirring shaft turns around the material barrel, at the same time, the stirring shaft is high-speed operation, so that the material is strong shearing action, achieve full dispersion and mixing effect. In addition to the equipment within the knife scraping wall around the cylinder axis rotation, will be stuck on the wall material scraping and then put them into mixing shear, that make no residual material in the mixer and mixing effect is more ideal.


    Product advantage and description

    In this machine, the two horizontal mixing shafts are mixed with the reverse equal-speed rotation, which can be realized the maneuvering discharge through the pneumatic piston push rod.Plasticity, ductility, briquettability concrete and all kinds of mortar can be mixed.Concrete mixer is advanced at home and abroad, the ideal model, and has a high degree of automation, mixing of good quality, high efficiency, low energy consumption, low noise, easy operation, long service life of lining and blade, fast discharging,convenient maintenance. Concrete mixer consists of feeding mechanism, mixing mechanism, discharging mechanism, water supply system, electric control system, etc. Applicable to plasticity, ductility, and lightweight aggregate concrete and various mortar mixing.Principle of Motion: Mixing with no hidden corners in the mixing pan by installing mixing tools and scraper tools on a specially designed drive system. The mixing track as follows.

    Steel Stationary Block Making Planetary Mixer PMC3000 High Homogenization Mixing 0
    Steel Stationary Block Making Planetary Mixer PMC3000 High Homogenization Mixing 1



    Technical Specification
    ITEM/(PMC) PMC
    50
    PMC
    100
    PMC
    150
    PMC
    250
    PMC
    330
    PMC
    500
    PMC
    750
    PMC
    1000
    PMC
    1250
    PMC
    1500
    PMC
    2000
    PMC
    2500
    PMC
    3000
    PMC 4000
    Feeding Capacity (L) 75 150 225 375 500 750 1125 1500 1875 2250 3000 3750 4500 6000
    Output Capacity (L) 50 100 150 250 330 500 750 1000 1250 1500 2000 2500 3000 4000
    Feeding Weight (kg) 120 240 360 600 800 1200 1800 2400 3000 3600 4800 6000 7200 9600
    Mixing Power (kw) 3 5.5 7.5 11 15 18.5 30 37 45 55 75 90 110 160
    Discharging Power (kw) Pneumatic Discharge(Hydraulic Discharge Optional) 3 3 3 4 4 4 4
    Mixing Star*Blade 1*2 1*2 1*2 1*2 1*2 1*2 1*3 2*2 2*2 2*2 3*2 3*3 3*3 3*3
    Side Scraper 1 1 1 1 1 1 1 1 1 1 1 1 1 1
    Discharge Scraper - - 1 1 1 1 1 1 1 1 2 2 2 2
    Weight (kg) 750 1000 1300 1500 2000 2400 3900 5500 6000 6500 9200 11000 12000 17500
    Lifting Power (kw) - - - 3 4 4 7.5 11 11 15 18.5 22 30 -
    Dimension (L*W*H) mm 950*
    790*
    1200
    1664*
    1453*
    1487
    1670*
    1460*
    1620
    1860*
    1650*
    1780
    1870*
    1870*
    1855
    2230*
    2080*
    1880
    2580*
    2340*
    2195
    2891*
    2602*
    2237
    3058*
    2756*
    2395
    3223*
    2902*
    2470
    3625*
    3230*
    2695
    3893*
    3550*
    2875
    3893*
    3550*
    3085
    4594*
    4150*
    3634





    Steel Stationary Block Making Planetary Mixer PMC3000 High Homogenization Mixing 2
