Home ProductsPlanetary Concrete Mixer

PMC2000 Planetary Counter Current MixerLow Energy Consumption

PMC2000 Planetary Counter Current MixerLow Energy Consumption

    • PMC2000 Planetary Counter Current MixerLow Energy Consumption
  • PMC2000 Planetary Counter Current MixerLow Energy Consumption

    Product Details:

    Place of Origin: JIAOZHOU CHINA
    Brand Name: PERMIX
    Certification: CE
    Model Number: PMC2000

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: Negotiation
    Packaging Details: Export Standard Package
    Delivery Time: 15-20 days
    Payment Terms: L/C, T/T
    Supply Ability: 5-10 units per month
    Contact Now
    Detailed Product Description
    Material: Steel Input Capacity: 3000L
    Weight: 9200kgs Bottom Scraper QTY: 3
    Side Scraper QTY: 1 Color: Orange
    High Light:

    commercial cement mixer

    ,

    hydraulic concrete mixer

    High Homogenization Of Planetary Mixing Counter Current Mixer 1-3 Unloading Doors PMC2000
    Features of Planetary mixer


    Planetary mixer is a new type of high efficiency, stirring without dead corner equipment; it has a unique form of stirring. Planet drive the two stirring shaft turns around the material barrel, at the same time, the stirring shaft is high-speed operation, so that the material is strong shearing action, achieve full dispersion and mixing effect. Mixer has good deaeration effect, the cylinder body can be designed to be heated or cooled according to customers' needs. The cover is hydraulic lifting, convenient to operate and clean and the cylinder body can move freely. Cylinder with special seal structure and have the pressure or vacuum stirring.


    Product advantage and description

    Concrete mixer is advanced at home and abroad, the ideal model, and has a high degree of automation, low energy consumption, low noise, easy operation, mixing of good quality, high efficiency, fast discharging, long service life of lining and blade, convenient maintenance. Applicable to plasticity, ductility, and lightweight aggregate concrete and various mortar mixing. In this mchine, the two horizontal mixing shafts are mixed with the reverse equal-speed rotation, which can be realized the maneuvering discharge through the pneumatic piston push rod.Concrete mixer consists of feeding mechanism, mixing mechanism, discharging mechanism,water supply system, electric control system, etc. Plasticity, ductility, briquettability concrete and all kinds of mortar can be mixed.



    Principle of Motion: Mixing with no hidden corners in the mixing pan by installing mixing tools and scraper tools on a specially designed drive system.
    The mixing track as follows.





    PMC2000 Planetary Counter Current MixerLow Energy Consumption 0







    Technical Specification
    ITEM/(PMC)PMC
    50
    PMC
    100
    PMC
    150
    PMC
    250
    PMC
    330
    PMC
    500
    PMC
    750
    PMC
    1000
    PMC
    1250
    PMC
    1500
    PMC 2000PMC
    2500
    PMC
    3000
    PMC 4000
    Feeding Capacity (L)7515022537550075011251500187522503000375045006000
    Output Capacity (L)501001502503305007501000125015002000250030004000
    Feeding Weight (kg)120240360600800120018002400300036004800600072009600
    Mixing Power (kw)35.57.5111518.5303745557590110160
    Discharging Power (kw)Pneumatic Discharge(Hydraulic Discharge Optional)3334444
    Mixing Star*Blade1*21*21*21*21*21*21*32*22*22*23*23*33*33*3
    Side Scraper11111111111111
    Discharge Scraper--111111112222
    Weight (kg)7501000130015002000240039005500600065009200110001200017500
    Lifting Power (kw)---3447.511111518.52230-
    Dimension (L*W*H) mm950*
    790*
    1200
    1664*
    1453*
    1487
    1670*
    1460*
    1620
    1860*
    1650*
    1780
    1870*
    1870*
    1855
    2230*
    2080*
    1880
    2580*
    2340*
    2195
    2891*
    2602*
    2237
    3058*
    2756*
    2395
    3223*
    2902*
    2470
    3625*
    3230*
    2695
    3893*
    3550*
    2875
    3893*
    3550*
    3085
    4594*
    4150*
    3634




    PMC2000 Planetary Counter Current MixerLow Energy Consumption 1
